[JAV-CT11, BT11] SERIES Air Vent for Steam (Capsule Type) Old Model: JKV-4C,JKV-4
A self operating air vent to be used for eliminating air or non condensable in steam, solving the air binding to ensure constant heat transferability and to prevent corrosion at the inside surface of pipe.
详细描述
■ Features
MODEL JKV-4 is a self operating air vent to be used for eliminating air or non condensable in steam, solving the air binding to ensure constant heat transferability and to prevent corrosion at the inside surface of pipe. As a bimetal operated air vent, the operating feature depends upon the temperature differential between steam and air which close the valve at the steam temperature and open while air or gas flows into the air vent.
■ Materials
NO
PART NAME
JAV-CT11
PART NAME
JAV-BT11
1
Body
FORGED BRASS
Body
CAST BRONZE
2
Cap
FORGED BRASS
Cap
CAST BRONZE
3
Seat
STAINLESS STEEL
Seat
STAINLESS STEEL
4
Capsule Ass'y
STAINLESS STEEL
Disc
STAINLESS STEEL
5
Spring
STAINLESS STEEL
Bimetal
NI-FE ALLOY
6
Screen
STAINLESS STEEL
Lock Nut
STAINLESS STEEL
7
Name Plate
STAINLESS STEEL
Washer
STAINLESS STEEL
8
Gasket
TEFLON
■ SPECIFICATIONS
1 . WORKING PRESSURE : MAX 14kgf/ cm2{1.4MPa},MAX10kgf/cm2{1.0MPa}
2 . WORKING TEMP : MAX 220℃
3 . CONNECTION : SCREWED
