[JHC-WI11] Hammerless Check Valve(WAFER) Old Model: JKHC-10
[JHC-WI11] JKHC-10 is designed for a lift check valve preventing pipe and equipment form water hammer and vibration and noise of water supply and drainage.
详细描述
■ MATERIAL
NO
PART NAME
JHC-WI11
1
Body
CAST IRON
2
Seat
CAST BRONZE
3
Disc Holder
DUCTILE CAST IRON
4
Disc
SYNTHETIC RUBBER
5
Disc Guide
CAST BRONZE
6
Spindle
BRONZE
7
Spring
STAINLESS STEEL
8
Upper Guide
DUCTILE CAST IRON
9
Nut
BRASS
10
Spilt Pin
STAINLESS STEEL
11
Gasket
SYNTHETIC RUBBER
12
By-Pass Valve
BRASS
■ Specifications
1. Applicable Fluid : Water
2. Working Pressure : MAX. 10 kgf/cm2
3. Working Temp. : MAX. 80℃
4. Connection : Wafer to suit KS10K
5. Hydro. Pressure Test : 20kgf/cm2
