[JST-YF01,YT41,YF41](Y Type) Old Model: JKSY SERIES
It is most popular usage for valves, nozzles, trap, pump suction slug and foreign material removing purpose and protect the equipment.

详细描述

■ Features
It is most popular usage for valves, nozzles, trap, pump suction slug and foreign material removing purpose and protect the equipment.
■ Materials
- CABON STEEL, STAINLESS STEEL, etc.
- KS, JIS, and ANSI sizes are all available.
■ Dimensions (Unit: mm)
JST-YF01
Size
d
L
L₁
L₂
Element
Plug
(PT)
d₁
ℓ
25A(1B)
34.0
270
60
195
24
191
½"
40A(1½B)
48.6
280
70
235
34
231
½"
50A(2B)
60.5
290
80
255
35
249
½"
65A(2½B)
76.3
320
85
295
50
291
½"
80A(3B)
89.1
320
90
326
60
321
¾"
100A(4B)
114.3
400
105
366
80
361
¾"
125A(5B)
139.8
450
110
420
105
412
¾"
150A(6B)
165.2
480
120
462
120
452
¾"
200A(8B)
216.3
580
150
551
170
538
¾"
250A(10B)
267.4
680
190
656
220
643
¾"
300A(12B)
318.5
800
210
756
260
743
¾"
350A(14B)
355.6
930
255
880
300
863
¾"
400A(16B)
406.4
1050
270
1015
340
1000
¾"
450A(18B)
457.0
1200
310
1115
400
1100
¾"
500A(20B)
508.2
1300
340
1215
450
1200
¾"

JST-YT41
Size
d
d₁
S
L
L₁
L₂
A
W
Element
d₂
ℓ
15A(½B)
15
21.8
9.6
100
30
68
45
8A
20
57
20A(¾B)
20
27.2
12.7
100
35
77
50
8A
28
57
25A(1B)
25
34.9
12.7
120
40
93
62
10A
35
68
40A(1½B)
40
48.9
12.7
155
55
133
75
15A
50
93

JST-YF41
Size
d
L
L₁
A[]
Element
d₁
K
15A(½B)
15
160
75
45
20
50
20A(¾B)
20
160
80
50
28
60
25A(1B)
24
200
100
62
35
75
40A(1½B)
40
250
150
75
50
110
